Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design

Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design

12ml Tube Filling Machine

Height 75cm Tube Filling Machine

Volumetric Piston Filling Machine

Place of Origin:

China

Brand Name:

XQ

Certification:

CE

Model Number:

XQQG

Contact Us
Request A Quote
Product Details
Speed:
1800 BPH
Pump:
Ceramic Pump(1-12ml)
Accuracy:
±0.8%
Size:
45*45*75cm
Weight:
15 KGS
Mold:
Customized
Driven:
Full Electric
Power:
220V 50/60Hz 50w
Suitable Product:
Non-stand-well Bottle
Material Contact Part:
Ceramic/SS 316L
Suitable Material:
Paste
Highlight:

12ml Tube Filling Machine

,

Height 75cm Tube Filling Machine

,

Volumetric Piston Filling Machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 20000-25000/ SET
Packaging Details
Wooden packing(130*75*75cm)
Delivery Time
20 Days
Payment Terms
T/T
Supply Ability
20 SETS per Month
Product Description

Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design



Universal Desktop Design Syringe Tube Piston Filling Machine With Precision Ceramic For Gel Tube



Characteristic:

This equipment has been tested to meet the requirements of GMP certification.



1. Adopt intelligent operating system.



2. High precision ceramic rotary valve is used to control liquid input and output, and precise ceramic plunger and cavity are ensured to be stable and precise.



3. 304 stainless steel appearance, desktop structure, practical and convenient.



4. Especially suitable for Cosmetic paste filling.



5. Convenient and rapid change of bottle species with different diameters.



6. Suitable for the gel tube, the pen core tube, the sealing tube, etc.



Technical parameters

Model XQQG-12 XQQG-25 XQQG-50 XQQG-100
Pump head High purity ceramics
Filling accuracy ≦±0.25%
 Filling range 1-12ml 2-25ml 5-50ml 10-100ml
Manufacturing speed 0-40 Bottle/min
Size of Host Machine 45*45*75cm
Power AC 220V 50-60Hz 50W
Air pressure 0.4-0.6Mpa

Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 0Universal Desktop Design Whiten Cream Piston Filling Machine With Hopper For Cosmetic

Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 1

This equipment has been tested to meet the requirements of GMP certification.



Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 2



Advantage of our piston pump:

1.The working pressure, volumetric efficiency and total efficiency are all the highest. Because the plunger and cylinder bore are easy to process, the dimensional accuracy and surface quality can reach very high requirements, so the matching accuracy is high, the oil leakage is small, and the working pressure that can be achieved is generally 20-40 MPa, and the highest can reach 100 MPa.


2.The transmittable power is the largest. As long as the plunger diameter or the number of plungers is increased appropriately, the flow rate will increase. High pressure and high current can transmit high power.



3.Wide speed range.


4.Long service life and high power density. The main parts of the plunger pump are under pressure, so that the material strength can be fully utilized, so use long life, and low weight per unit power.


5.Good bidirectional variable capacity. Changing the stroke of the plunger can change the flow rate, making it easy to make various variable types.



Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 3 Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 4Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 5Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 6Full Electric Piston Syringe 12ml Tube Filling Machine Desktop Design 7
