Full Automatic 2L Liquid Shampoo Filling Capping Machine With High Quality Filling System For The Shampoo Industry PackFull Automatic 2L Liquid Shampoo Filling Capping Machine With High Quality Filling System For The Shampoo Industry Pack
Characteristic of Full Automatic 2L Liquid Shampoo Filling Capping Machine
Tracking type high-speed double heads filling machine consists of chain conveyor, bottle clamping automatic alignment mechanism, filling mechanism, automatic servo piston system, electric lifting adjustment mechanism, waterproof electric cabinet, touch man-machine operation interface, etc. This machine has the function of one-button quick changeover, which can be applied to the automatic filling equipment for bottles of different specifications.
Characteristic of Full Automatic 2L Liquid Shampoo Filling Capping Machine
A. Material contact parts are made of stainless steel SUS316.
B. Adopt photoelectric control, fast and accurate automatic quantitative filling; The rotary valve adopts ceramic material without sealing ring, cleaning without dead angle.
C. Using motion controller and HMI man-machine operation interface, parameters can be called on the operation interface with one key without manual adjustment of the mechanical position.
D. Servo system is adopted, with high filling precision and precise positioning.
E. The filling action is fast so that the bottle can be filled immediately, and the production efficiency is high.
F. The whole machine adopts a stainless steel frame structure, transparent PC or plexiglass material frame, SUS304 stainless steel countertop.
G. Ultrasonic liquid level control.
H. Adopting motion control system and servo motor for tracking capping, the bottle does not need to be stopped, and the position of the bottle is automatically tracked for automatic capping, and the torque can be adjusted
Technical data of Full Automatic 2L Liquid Shampoo Filling Capping Machine
| Production efficiency |
2400-3000BPH (using 300ML paste material as the test standard) |
| Filling range |
50-1000ml |
| Filling accuracy |
±0.4% |
| power |
6KW 220V 50Hz |
| Air pressure |
0.6~0.8Mpa total air consumption: about 1.8 cubic meters per minute |
| Size |
The length of the whole line is according to the actual design plan |
Product display
Service of HonkyTech:
Pre-sales:
According to client requirements, supply reasonable mаsk machine sketch map, quotation and operation video for client ref first.
During Sales:
1) Depends on client objects, made reasonable reform based on the standard machine.
2) 24-hour uninterrupted test before machine delivery, make sure machine operation stable.
3) Execute SGS certification for the equipment and materials used in the production process requirement and specification strictly.
After-sale:
1. Provide complete teaching videos and materials, easy to operate and simple to maintain.
2. Experienced engineers provide online or computer guidance.
3. If in South Korea, we have a professional technical team that can provide door-to-door service.
4. Guarantees all equipment (except human factors) within one year, lifetime maintenance service.
5. After machine used for several years, SKILT promise to provide detailed refurbishment program, the original equipment and replacement of hardware and software upgrades, extending machine service life for more than 3-4 years.
