| Place of Origin: | China |
|---|---|
| Brand Name: | XQ |
| Certification: | CE |
| Model Number: | XQHFL-110 |
| Minimum Order Quantity: | 1 Set |
| Price: | USD 12000-13000 Per Set |
| Packaging Details: | Wooden packing |
| Delivery Time: | 10 Days |
| Payment Terms: | T/T |
| Supply Ability: | 10 Sets per Month |
| Warranty: | 12 Months | Type: | Pillow Packing Machine |
|---|---|---|---|
| Efficiency: | 40-150 Bag Per Minute | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Usage:: | Food /medicines/cosmetic |
| Highlight: | 40 BPM Horizontal Flow Wrap Machine,40 BPM Flow Wrap Packing Machine,40 BPM Pillow Packing Machine |
||
Automatic 40 BPM Horizontal Flow Wrap Machine For Food Cosmetic
Automatic Horizontal Flow Wrap Machine For Food And Cosmetic Packing
Characteristic
The bag length requires no manual setting. The machine can automatically detect and set the length; The Dual-VFD simple mechanic structure is stable, which requires easy maintenance, and of low-wearing and long-running life; The main control adopts SCM, digital display and controlled by VFD. Friend HMI makes operation direct and easy; Running speed and the length of the bag are controlled by two VFDs, with stepless speed shift and wide adjustment range, which makes matching well with the upstream machines possible; High sensitive photocell eyes system makes tracking accurate; Independent temperature control for each sealing device (mid sealing and end sealing), which is suitable for a wide variety of packing materials. Device for intermission air charging and alcohol spray can be mounted (only for the food industry).
Technical data
| Model | XQHFL-110 |
| Film Width | Max.250mm |
| Bag Length | 65-280mm |
| Bag Width | 30-110mm |
| Product Height | Max.45mm |
| Speed | 40-230 Bag/min |
| Power | 220V 50/60Hz 2.4KW |
| Machine Size | 3920*670*1320 mm |
| Weight | About 500 KG |
